MHT

drive mode left and right hand drive
Structural features
integrated bridge"
Vehicle weight 700kg
Number of passengers 5peoples
Material metal shell + plastic steel parts
voltage 72v
battery 72v 300ah
LxWxH(mm) 3050X1600×1500
Wheelbase(mm) 2200mm
Maximum grade ≥35%
Brake system
four-wheel disc brake system"
Shock absorption system
four-wheel hydraulic shock absorption"
Motor power
10kW AC motor"
Peak power (kW) 20kw
Peak torque (Nm) 140N.m
Rated battery voltage （v) V:DC96V
Rated voltage(v) V:AC61V
Rated torque N.m:31.8N.m
Rated speed rpm:3000rpm
Maximum rotational speed rpm:6500rpm
Work system S2-60min
Ambient temperature 40℃
Rim material
luxury aluminum alloy wheels
"
Tire specifications 175-70R13
Insulation class H级
Degree of protection IP54
